Titanium Spring Washers, Titanium Grade 2 & Grade 5 Spring Lock, Split Ring & Helical Washers Supplier in Mumbai, India
Unifit Metal Alloys is a manufacturer, supplier, stockist and exporter of Titanium Spring Washers in Mumbai, India, supplying lightweight fastening components for engineering equipment, industrial machinery, fabrication and specialized mechanical assemblies. These washers are manufactured from titanium materials selected for their favorable strength-to-weight ratio and resistance to corrosion in demanding environments. We offer different diameters, thicknesses and configurations to suit various fastening requirements. Standard and customized dimensions can also be supplied.
Titanium Spring Washers are installed beneath nuts or bolt heads to provide resilient loading within threaded connections and help maintain fastening pressure during service. Their spring action helps preserve contact between mating surfaces and can accommodate minor movement and vibration in the joint. Titanium offers excellent resistance to moisture, seawater and many corrosive media while maintaining a comparatively low weight, making these washers useful for applications where both corrosion resistance and weight reduction are important.
Titanium Spring Washer, Titanium Grade 2 & Grade 5 Spring Lock, Split Ring & Helical Washer Manufacturer & Supplier in India
These washers are suitable for aerospace components, marine equipment, chemical processing systems, offshore machinery, medical equipment, power-generation assemblies and specialized engineering applications. Titanium spring washers can be selected for environments where conventional metallic materials may be affected by corrosion or where lightweight construction is required. Different sizes, thicknesses and configurations can be supplied according to the fastener dimensions and application conditions.
At Unifit Metal Alloys, we supply Titanium Spring Washers in various sizes, thicknesses, grades, configurations and surface finishes for standard and specialized industrial requirements. We cater to maintenance needs, bulk quantities and project-based orders.
Get the Best Quote for Titanium Spring Washers. We Stock Titanium Spring Washers in Various Diameters, Thicknesses, Sizes, Grades, Types and Surface Finishes. Contact Us Today for a Competitive Quote.
Specifications of Titanium Spring Washer
| Material | Titanium |
|---|---|
| Grades | Titanium Grade 2, Titanium Grade 5 |
| UNS | R50400, R56400 |
| Werkstoff No. | 3.7035, 3.7165 |
| Equivalent Grades | Commercially Pure Titanium Grade 2, Ti-6Al-4V Grade 5 |
| Standard | DIN 127, DIN 7980, ASME B18.21.1, ISO 8748 |
| Size Range | M3 to M100 |
| Type | Split Lock Washer, Helical Spring Washer |
| Shape | Split, Helical |
| Surface Finish | Plain, Polished, Passivated |
| Manufacturing Process | Cold Formed, Stamped, Heat Treated |
| Corrosion Resistance | Excellent Resistance to Seawater, Chlorides, Oxidation and Corrosive Environments |
| Temperature Resistance | High Temperature Service |
| Application | Aerospace, Marine, Chemical Processing, Oil & Gas, Petrochemical, Power Generation |
| Packaging | Boxes, Cartons, Bulk, Individual Packs |
Titanium Spring Washer Dimensions Chart
| Size | Inside Diameter (mm) | Outside Diameter (mm) | Thickness (mm) |
|---|---|---|---|
| M3 | 3.2 | 6.0 | 0.5 |
| M4 | 4.3 | 7.0 | 0.8 |
| M5 | 5.3 | 9.0 | 1.0 |
| M6 | 6.4 | 10.0 | 1.6 |
| M8 | 8.4 | 13.0 | 2.0 |
| M10 | 10.5 | 17.0 | 2.5 |
| M12 | 13.0 | 21.0 | 3.0 |
| M14 | 15.0 | 24.0 | 3.0 |
| M16 | 17.0 | 27.0 | 3.5 |
| M18 | 19.0 | 30.0 | 3.5 |
| M20 | 21.0 | 34.0 | 4.0 |
| M22 | 23.0 | 37.0 | 4.0 |
| M24 | 25.0 | 40.0 | 5.0 |
| M27 | 28.0 | 44.0 | 5.0 |
| M30 | 31.0 | 50.0 | 6.0 |
You need our support, to
have any projects?
Equivalent Grade of Titanium Spring Washer
| Grade | UNS | Werkstoff No. | EN | Equivalent Grade |
|---|---|---|---|---|
| Titanium Grade 2 | R50400 | 3.7035 | Ti Grade 2 | Commercially Pure Titanium Grade 2 |
| Titanium Grade 5 | R56400 | 3.7165 | Ti-6Al-4V | Ti-6Al-4V / Alloy 5 |
Ready Stock of Titanium Spring Washer
Titanium Spring Washer Application Industries
