Titanium Round Bar

Titanium Round Bars, Titanium Alloy Round Bars & Industrial Titanium Round Bars Supplier in Mumbai, India

Unifit Metal Alloys is a manufacturer, supplier and exporter of Titanium Round Bars in Mumbai, India, supplying titanium products for demanding engineering, fabrication and industrial applications. We offer Titanium Round Bars in different grades, diameters, lengths and surface finishes to meet standard as well as customized requirements.

Our Titanium Round Bars are valued for their high strength-to-weight ratio, excellent corrosion resistance and good dimensional stability. Their lightweight construction combined with reliable mechanical properties makes them suitable for components that require durability without adding unnecessary weight.

Titanium Round Bar, Titanium Steel Round Bar and Titanium Alloy Round Bar Manufacturer & Supplier in India

We supply Titanium Round Bars in standard stock sizes as well as customized dimensions according to customer drawings and technical specifications. Depending on the application, bars can be provided with bright, polished, ground or machined surfaces. Forged and specially processed bars can also be supplied for applications requiring enhanced strength and structural integrity.

Titanium Round Bars are commonly used in aerospace, marine, chemical processing, pharmaceutical, power generation, medical equipment, oil and gas and general engineering industries. They are suitable for manufacturing shafts, fasteners, valve components, pump parts, machined components and other critical industrial parts. At Unifit Metal Alloys, we focus on maintaining consistency in material grade, dimensional accuracy, surface finish and overall product quality. Material Test Certificates and inspection documentation can be provided according to customer and project requirements.

Get the Best Quote for Titanium Round Bars. We Stock Titanium Round Bars in Various Diameters, Lengths, Sizes and Material Specifications. Contact Us Today for a Competitive Quote.

Specifications of Titanium Round Bar

Specifications
Titanium Alloy Round bar size Diameter: 3-~800mm
Titanium Super Alloy Hex Bar size 2-100mm A/F
Titanium Steel Alloy Flat bar size Thickness: 2 -100mm
Width: 10 to 500mm
Titanium Alloy Square bar size 4 to 100mm
Titanium Angle bar size (in mm) 3*20*20~12*100*100
Titanium Wrought Alloy Section 3.0 to 12.0mm thickness
Ti Alloy Channel Bar (in mm) 80 x 40 to 150 x 75 section; 5.0 to 6.0 thickness
Alloy Titanium Hollow Bar (in mm) 32 OD x 16 ID to 250 OD x 200 ID)
Ti Alloy Billet Size 1/2″ to 495mm Diameter
Titanium Rectangles Size 33 x 30mm to 295 x 1066mm
Titanium Super Alloy Round Bar Finish Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
Titanium Steel Alloy Round Bar Surface Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline
Titanium Round Bar Condition Hardened & tempered, annealed
Titanium Wrought Alloy Bar Technique Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod
Titanium Alloy Round Bar Tolerance H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Titanium Alloy Bar Processing Bar cutting to 650mm
Our Titanium Round Bar stockyard in India Mumbai, Chennai, Ahmedabad, Gujarat, Agra, Bengaluru, Shivamogga, Hyderabad, Tiruchirappalli, Pimpri-Chinchwad, Bhubaneswar, Noida, Tirunelveli, Pune, Coimbatore, Thiruvananthapuram, Dhanbad, Navi Mumbai
Our Titanium Steel Alloy Round bar conforms to NACE MR0175/ISO 15156

Titanium Round Bar Chemical Composition

Grade C N O H Ti Fe
Gr 1 .08 Max .03 Max .18 Max .015 Max Bal .20 Max
Gr 4 .08 Max .05 Max .40 Max .015 Max Bal .50 Max
Gr 7 .08 Max .03 Max .25 Max .015 Max Bal .30 Max
Gr 9 .08 Max .03 Max .15 Max .015 Max – .25 Max
Gr 12 .08 Max .03 Max .25 Max 0.15 Max – .30 Max

You need our support, to
have any projects?

Get Free Quotes
Contact Us

Titanium Round Bar Weight Chart

Weight Chart
Size Kgs / Foot Kgs / Mtr Size Kgs / Foot Kgs / Mtr Size Kgs / Foot Kgs / Mtr
3mm 0.017 0.055 20mm 0.753 2.470 3″ 10.900 35.762
1/8″ 0.019 0.062 22mm 0.908 2.979 3-1/4″ 12.800 41.996
5/32″ 0.029 0.095 7/8″ 0.926 3.038 3-1/2″ 14.850 48.772
4mm 0.030 0.098 24mm 1.080 3.543 3-3/4″ 17.001 55.780
3/16″ 0.043 0.141 25mm 1.180 3.871 4″ 19.306 63.340
5mm 0.047 0.154 1″ 1.210 3.970 4-1/4″ 21.908 72.249
7/32″ 0.058 0.190 26mm 1.271 4.170 4-1/2″ 24.4487 80.340
6mm 0.068 0.223 27mm 1.368 4.490 4-3/4″ 27.366 90.249
1/4″ 0.076 0.249 1-1/8″ 1.534 5.033 5″ 30.461 99.940
7mm 0.091 0.298 30mm 1.691 5.548 5-1/2″ 36.690 121.000
5/16″ 0.118 0.387 1-1/4″ 1.924 6.349 6″ 43.860 143.900
8mm 0.120 0.398 32mm 1.894 6.314 6-1/2″ 51.093 167.630
9mm 0.152 0.498 1-3/8″ 2.303 7.550 7″ 59.432 196.000
3/8″ 0.170 0.557 35mm 2.390 7.553 7-1/2″ 68.226 225.000
10mm 0.189 0.620 36mm 2.438 7.999 8″ 77.586 254.55
11mm 0.228 0.748 38mm 2.792 8.903 10″ 121.048 397.140
7/16″ 0.232 0.761 1-1/2″ 2.715 8.951
12mm 0.271 0.889 40mm 3.009 9.872
1/2″ 0.303 0.994 1-5/8″ 3.200 10.449
13mm 0.318 1.043 1-3/4″ 3.712 12.179
14mm 0.368 1.207 45mm 3.807 12.555
9/16″ 0.383 1.256 1-7/8″ 4.260 13.977
15mm 0.424 1.391 48mm 4.330 14.205
5/8″ 0.473 1.551 50mm 4.698 15.414
16mm 0.481 1.578 2″ 4.848 15.906
17mm 0.543 1.791 2-1/8″ 5.475 17.963
11/16″ 0.573 1.880 2-1/4″ 6.135 20.128
18mm 0.610 2.001 60mm 6.768 22.205
3/4″ 0.682 2.237 2-3/8″ 6.838 22.435
2-1/2″ 7.576 24.856
2-5/8″ 8.354 27.409
2-3/4″ 9.169 30.083

Ready Stock of Titanium Round Bar

Titanium Grade 2 Round Bars
Titanium Grade 5 Round Bars
Titanium Alloy Round Bars
Titanium Forged Round Bars
Titanium Precision Round Bars
Titanium Ground Round Bars
Titanium Bright Round Bars
Titanium Hot Rolled Round Bars
Titanium Cold Drawn Round Bars
Titanium Machined Round Bars
Titanium Annealed Round Bars
Titanium Polished Round Bars
